DRILLS

DTC 30 GEAX

TORQUE: 19.900 F -LBS

DRILLING DIAMETER: 42''

DRILLING DEPTH: 47.5 FT

BASE MACHINE: KUBOTA V2607

DRILL SPEED: 0 - 45 rpm

MAIN WINCH: 7.800  lbf

MACHINE WEIGHT: 20.950 lb

DTC 80 GEAX

TORQUE: 80,000 FT-LBS

DRILLING DIAMETER: 10 FT

DRILLING DEPTH: 60 FT

BASE MACHINE: KOMATSU PC290 LC -11

DRILL SPEED: O TO 60 RPM

CROWD STROKE: 168"

CROWD FORCE: 35,000 LBS

KELLY WINCH: 30,000 LB LINE PULL

SERVICE WINCH: 12,000 LB LINE PULL

SIDE TILT: 10 DEGREE LEFT/RIGHT

KELLY BARSET: 4 ELEMENT SQUARE (5" INNER)

ATTACHMENT WEIGHT: APPROX 12,500 LBS

TRANSPORT WEIGHT: APPROX 81,500 LBS

TOWER DRILL

TORQUE: 1,800 FT-LBS

DRILLING DIAMETER: 24"

DRILLING DEPTH: 40FT

DRILL SPEED: 0-80 RPM

CROWD STROKE: 72"

CROWD FORCE: 3,750 LBS

KELLY WINCH: 2800 LINE PULL

ATTACHMENT HEIGHT: 8 FT

ATTACHMENT WEIGHT: APPROX 800 LBS

POWER REQUIREMENTS: 25 GPM@ 2,200 PSI
